汽車分動箱起什麼作用?——What is the function of the transfer case?



汽車分動箱起動力分配和降速增矩的作用。

分動箱是四驅車傳動系統中不可缺少的傳動部件。分動箱把發動機輸出的驅動力分配到前軸,或者前後軸各驅動輪,並進一步增大扭矩。分動箱由齒輪傳動,所以保養需要使用齒輪油,齒輪油可以給齒輪和軸承潤滑和散熱,還有防止磨損和銹蝕的作用。

差速器和分動箱的區別是:區別在於主要功能不同,工作狀態不同,崗位不同。

在普通家用車的範圍內,差速器負責調節前後軸的速度差,而分動箱則負責將變速箱輸出軸的動力一分為二,從前後驅動橋輸出,一般作為一個整體使用。分動箱為齒輪傳動系統,其輸入軸直接或通過萬向傳動裝置與變速器的第二軸連接,多個輸出軸分別通過萬向傳動裝置與各驅動橋連接。

分動箱是變速箱後面的變速箱。

它的作用是將變速箱的動力分配到前後軸,然後帶動四個輪胎轉動。在多軸驅動汽車中,為了將從變速器輸出的動力分配到每個驅動軸,通常安裝一個分動箱。分動箱的基本結構也是齒輪傳動系統,其中輸入軸直接與變速器的第二軸連接或通過萬向傳動裝置連接,輸出軸有幾個,分別過萬向傳動裝置與各驅動橋連接。普通差速器,雖然可以讓左右車輪以不同的速度轉動,但當其中一人車輪空轉動時,好路上的另一人車輪得不到扭矩汽車在市區就失去了驅動力。在這種情況下,差速器不起作用。這樣,兩個車輪連接在一起,至少可以將動力傳遞給另一個車輪,讓汽車獲得驅動力,擺脫困境。這種情況在中央差速器中也存在,因此人們開發了各種差速器鎖止機構

——————————————————————————————————————

The transfer case of a vehicle serves to distribute power and to reduce speed and increase torque.
The transfer case is an indispensable transmission component in the transmission system of a four-wheel drive vehicle. The distributor distributes the drive power from the engine to the front axle, or to each of the front and rear axle drive wheels, and further increases the torque. The gearbox is driven by gears, so maintenance requires gear oil, which lubricates the gears and bearings and dissipates heat, as well as preventing wear and corrosion.

The difference between a differential and a transfer case is.The difference lies in the different main functions, the different operating conditions and the different positions.

In the context of ordinary domestic vehicles, the differential is responsible for regulating the speed difference between the front and rear axles, while the transfer case is responsible for splitting the power from the transmission's output axles into two, which are output from the front and rear drive axles, and is generally used as a whole. The transfer case is a gear transmission system in which the input shaft is connected to the second shaft of the gearbox either directly or via a universal transmission, and the multiple output shafts are connected to the drive axles via universal transmissions.
The transfer case is the gearbox behind the transmission. Its function is to distribute the power from the gearbox to the front and rear axles and then to drive the four tyres. In multi-axle drive vehicles, a transfer case is usually installed in order to distribute the power from the transmission to each drive axle. The basic structure of the transfer case is also a gear transmission system, in which the input shaft is connected directly to the second shaft of the transmission or via a universal transmission, and the output shaft is connected to each drive axle via a universal transmission. With an ordinary differential, although the left and right wheels can rotate at different speeds, when one of the wheels is idling, the other wheel on the good road does not get the torque and the car loses drive in the city. In this case, the differential does not work. In this case, the two wheels are connected so that at least one wheel can transfer power to the other, allowing the car to gain drive and get out of trouble. This is also the case with central differentials, which has led to the development of various differential locking mechanisms
